Diamond Audio
Diamond Audio DXM1000.6D - 6-Channel 1000W RMS Full Range Class D Waterproof Amplifier
Part #: DXM1000.6D
Ships direct from supplier
Item ships direct from supplier when available. Some items will be in stock and ship immediately, and others will have a lead time. Please contact us for more information. You will receive a lead time confirmation upon placing an order.
From $859.99
Diamond Audio DXM1000.6D - 6-Channel 1000W RMS Full Range Class D Waterproof Amplifier—
$859.99
Fits These Vehicles
Fits These Vehicles
Shipping & Returns
Shipping & Returns
Description
DXM1000.6D - 6-Channel Full Range Class D Waterproof Amplifier
IPX67 RATED Waterproof multi-layer circuit boards for marine applications - Balanced differential inputs for noise-free operation regardless of the source - Full-range digital Class D technology with Direct FET power MOSFET output stage - 12dB per octave adjustable crossovers and phase control for system tuning. Selectable 3 option Auto Turn-On Mode circuit designed to work with ANY OEM head-unit, simplifies installation.Features:
- 170W x 6CH @ 2? / 110W x 6CH @ 4? / 340W x 3CH @ 4? Bridged RMS Power Output
- Input Sensitivity: 0.2-10 Volt
- Crossover Filter : 40-400Hz, 12dB Per Octave Slope
- Frequency Response: 10-33KHz
- Selectable X-Over: LPF / FULL / HPF
- Selectable 2CH / 6CH Input Modes
- Dimensions: 11.76? x 4.33? x 1.73? / 298.6 x 110 x 44.0 mm
- RCA Input & Speaker & Power Supply Harness Kits and Remote Bass Knob Included
| Amplifier | 6 Channel |
|---|---|
| RMS Power(2?) | 150W X 6 |
| RMS Power (4?) | 100W X 6 |
| RMS Bridge (mono 4?) | 300W X 3 |
