Diamond Audio MICRO85U - 5-Channel 950W RMS Full Range Class D Amplifier
Part #: MICRO85U
Ships direct from supplier
Item ships direct from supplier when available. Some items will be in stock and ship immediately, and others will have a lead time. Please contact us for more information. You will receive a lead time confirmation upon placing an order.
From $659.99
Diamond Audio MICRO85U - 5-Channel 950W RMS Full Range Class D Amplifier—
$659.99
Fits These Vehicles
Fits These Vehicles
Shipping & Returns
Shipping & Returns
Description
MICRO85U - 5-Channel Full Range Class D Amplifier
Diamond Audio continues to break new dimensions by introducing the MICRO8U series of amplifiers for 2018. Following in the footsteps of the highly popular MICRO series amplifiers, the big-brother MICRO8U series packs more power and performance! Developed and engineered from the ground up, these new amplifiers not only deliver more power, they are conformal-coated for all-weather application and outdoor environment use. All MICRO8U models have the same platform and dimension size excluding the MICRO85U & MICRO88U) for a more aesthetically pleasing installation/fabrication set up to match its subtle, yet elegant cosmetics to give it that signature Diamond Audio visage. Features:- 150W x 4CH + 350W @ 2? / 80W x 4CH + 200W @ 4?
- Input Sensitivity: 0.2-10 Volt
- Crossover Filter :
- Fixed 75Hz (HPF) 12dB Per Octave Slope ( CH1/CH2/CH3/CH4 )
- 40-400Hz, 12dB Per Octave Slope ( CH5/CH6/CH7/CH8 )
- Frequency Response: 10-33KHz
- Selectable REM / VOX / DC Turn On Modes
- Selectable 2CH / 5CH Input Modes
- Independent Front & Rear & Sub Inputs
- Dimensions: 10.45? x 4.02? x 1.4? (265.6 x 100.11 x 35.56 mm)
- Disconnected RCA Input & Speaker Output (Front & Rear) Harness Kits Included
| MAX Power Rating | 950 W RMS |
|---|---|
| RMS Power(2?) | 150W X 4 + 350W X 1 |
| RMS Power (4?) | 90W X 4 + 200W X 1 |
| RMS Bridge (mono 4?) | 300W X 2 |
