Diamond Audio

Diamond Audio MP654 - 6.5" PRO Full-Range Co-Ax Horn Speaker

Part #: MP654
Ships direct from supplier

Item ships direct from supplier when available. Some items will be in stock and ship immediately, and others will have a lead time. Please contact us for more information. You will receive a lead time confirmation upon placing an order.

From $439.99
Diamond Audio MP654 - 6.5" PRO Full-Range Co-Ax Horn Speaker—
$439.99

Fits These Vehicles

Shipping & Returns

Description

  • 150W RMS/300 MAX Power Handling
  • Ferrite Strontium High Temp Magnet structure
  • Heavy Duty Die-cast Aluminum Basket
  • 1.5? 4 Ohm ? Single Layer High Temp Voice Coil with Black Coated Voice Coil former for Woofer
  • 1.0? 8 Ohm ? Single Layer High Temp Voice Coil for Tweeter
  • Advanced Voice Coil Heat Sink Design for Better Heat Dissipation
  • Frequency Response: 110Hz -18Khz
  • High Sensitivity 101dB 1W/1M
  • 12dB Crossover
  • Mounting Depth: 3.33? / 84.6mm
  • Mounting Diameter: 5.73? / 145.5mm

Specifications

SPL (dB-MidBass) 92.7
SPL (dB-Tweeter) 107
Re(?) 3.2
Qms 10.73
Qes 0.47
Qts 0.45
Fs(Hz) 103.3
Vas(L) 6.6
Cms(mm/N) 0.24
Mms(g) 9.7
Sd(m2) 138.9
BL(T*M) 6.5
Xmax(mm) 1.0
Pwr(W) NOM/MAX 150/**300
Total Diameter 6.52 (165.5) in. (mm)
Mounting Diameter 5.73 (145.5) in. (mm)
Mounting Depth 3.33 (91.6) in. (mm)
Total Depth 3.88 (98.6)in. (mm)
Magnet Diameter 3.94 (100) in. (mm)
