'99 model engines using key way camshafts/sprocket will need to purchase new spline style rear cam sprocket separately.
Features
- Fierce performing camshaft for an array of engine sizes, large displacement 103", 110" and 124" engines looking for a superior torque band with excellent horsepower gains in heavy bikes (2200-6250 rpm)
- Smaller high-revving displacement 95" style engines in lighter bikes looking to twist the throttle and tap into some horsepower (2500-6800 RPM)
- Large displacements respond well to increased compression ratio and smaller displacements will require it
- 594 cams require high-performance valve springs, pushrods, lifters, carburetor or throttle body work, performance exhaust, intake and clutch
- Made in the USA
Specs
| Application | Intake |
| Intake Lobe Centerline | 108.5° |
| Model | Reaper |
| Riding Style | Street |
| Exhaust Lift | 0.604" |
| Exhaust Close | 16° |
| Exhaust Lift at TDC | 0.167" |
| Exhaust Open | 64° |
| Intake Close | 56° |
| Intake Open | 19° |
| Intake Duration | 255° |
| Intake Lift at TDC | 0.190" |
| Exhaust Lobe Centerline | 114° |
| Product Name | Camshaft |
| Units | Pair |
| Intake Lift | 0.594" |
| Type | Chain |
| Exhaust Duration | 260° |
| Grind | 594 Series |
