Target Ride Length: 11".
Target Ride Length is the length of the selected shocks, installed, and as measured between the upper and lower shock mounts. When the full weight of the rider(s) and gear are on the bike and ready to ride. This is a fast and easy way to set your rear suspension at optimum Ride Sag (1/3 of total suspension travel).
Features
- The perfect balance of lowered stance and ride quality
- Combine a flat-wire spring with a progressive main spring, the 12.5” shock sits like 11.5” units under the weight of the bike, yet utilizes the full stroke as terrain demands it
- The result is a lowered shock that rides like a traditional height unit
- Five position preload adjuster
- Gas charged damper
- Available in black or chrome
Specs
| Color/Finish | Black |
| Product Name | Shock Absorber |
| Units | Pair |
| Duty | Standard |
| Progressive Spring Rate | 90.00 lb/in - 130.00 lb/in |
| Damping Method | Gas Charged |
| Mounting Position | Rear |
| Reservoir Location | Internal |
| Type | Coilover Monotube |
| Extended Length | 12.50" |
| Material | Steel |
| Adjustment Style | Automatic |
| Riding Style | Street |
| Spring Type | Single Progressive Rate |
| Model | 412 Cruiser Series |
Fitment
1995, 1997-1998, 2010, 2012-2013, 2015, 2019 Harley-Davidson XL1200C Sportster 1200 Custom1977-1978 Harley-Davidson XLCR Cafe Racer
2012, 2014-2015 Harley-Davidson 1200 XLCP
1990, 1992, 1994-1995, 1997, 1999, 2001, 2003 Harley-Davidson Sportster 883 XLH
2010, 2013, 2020-2022 Harley-Davidson XL1200X Forty-Eight
2016, 2020 Harley-Davidson XL1200CX Roadster
2013-2014, 2017, 2019 Harley-Davidson XL883L SuperLow
2010, 2012, 2016, 2019 Harley-Davidson XL883N Iron 883
2018 Harley-Davidson XL1200XS Forty-Eight Special
2016 Harley-Davidson XL1200T SuperLow 1200T
2014 Harley-Davidson XL1200V Seventy-Two
2009-2010 Harley-Davidson XL1200N Sportster 1200 Nightster
2007, 2009 Harley-Davidson XL1200L Sportster 1200 Low
2004-2005, 2008-2009 Harley-Davidson XL1200R Sportster 1200 Roadster
2007 Harley-Davidson XL50 50th Anniversary Sportster
2007 Harley-Davidson XL883C Sportster 883 Custom
2006 Harley-Davidson XL883 Sportster
1988, 1990-1991, 1998, 2001, 2003 Harley-Davidson XLH883HUG Sportster 883 Hugger
1988, 1991, 1995, 1997, 1999-2000, 2002 Harley-Davidson XLH883
1988-1991, 1994-1995, 1997-1998 Harley-Davidson XLH1200
1994-1996 Harley-Davidson XLH883DLX Sportster 883 Deluxe
2020 Harley-Davidson XL1200NS Iron 1200
Fitment details provided by supplier.
