Tools & Hardware

Jims 1705 - Exhaust Drill Plate

Exhaust Stud Drill Plate Will position the seal evenly into the exhaust port of head Tool can be used with exhaust flange nuts Made in the U.S.A.

Jims 1710 - Outer Race Snap Ring

Snap Ring Tool Used for removing and installing the Timken® bearing outer race snap ring A must for replacing rings in OEM and aftermarket cases Made in the U.S.A.

Jims 1720 - Main Bearing Remover - 5-Speed

Main Drive Gear Bearing Removal Tool Removes old bearing straight and will not damage the transmission case Can be used without removing transmission from the bike Made in the U.S.A.

Jims 1726-1 - Bushing Reamer - Wrist Pin

Wrist Pin Bushing Reaming Tool Some wrist pin bushings will require a small amount of ball honing to give specified fit (see H-D manual for specifications). Used to ream wrist pin bushings to the proper inner diameter Can be used with rods in or out...

Jims 1726-2 - Bushing Reamer - Wrist Pin

Wrist Pin Bushing Reaming Tool Some wrist pin bushings will require a small amount of ball honing to give specified fit (see H-D manual for specifications). Used to ream wrist pin bushings to the proper inner diameter Can be used with rods in or out...

Jims 1726-3 - Bushing Reamer - Wrist Pin

Wrist Pin Bushing Reaming Tool Some wrist pin bushings will require a small amount of ball honing to give specified fit (see H-D manual for specifications). Used to ream wrist pin bushings to the proper inner diameter Can be used with rods in or out...

Jims 1743 - Swingarm Bushing Tool

Swingarm Bushing Tool Allows installation of delicate, silicone cleveblock bushings in swingarm without damage Tool presses on outer sleeve of bushing Can be used with or without a press

Jims 1776 - Compressor Fork - Front

Front Fork Compressor Tool Also includes FLT adapter for FLT forks to eliminate direct contact with spring coil and special rod to pull up fork damper rod Tool compresses springs in cartridge-style forks when servicing or rebuilding Can be mounted in...

Jims 1803 - Hydrosolid Tappet - XL

Hydrosolid Tappets Perform like a hydraulic tappet up to 5500 rpm, then turn into a solid tappet When they turn into solid tappets, it adds approximately three to six more usable horsepower Prevent hydraulic pump at high rpms Made in the U.S.A. ...

Jims 2043 - Fork Nut Socket - 41 mm

Fork Nut Socket Eliminates possible burring of plug caused by wrenches Used to remove and install top fork-tube plug Fits 41 mm forks Made in the U.S.A.

Jims 2046 - Fork Seal Installer - 39 mm

Fork Seal and Cap Installer Lightly grease to keep from scratching fork tubes Used to install fork and dust seals Made in the U.S.A.

Jims 2047 - Fork Seal Installer - 41 mm

Fork Seal and Cap Installer Lightly grease to keep from scratching fork tubes Used to install fork and dust seals Made in the U.S.A.

Jims 2049 - Fork Seal Installation Tool - 49 mm

49mm Fork Seal and Dust Shield Installer Installs lower leg 49 mm fork seals squarely into the bore without damaging the seal lip surface Designed for specific Harley-Davidson® models except inverted fork models Two-piece design to aid in some...

Jims 2232 - Bearing Race Tool

Steering Head Bearing Race Tool Removes and installs steering head bearing race on 84-16 Big Twin (except 14-16 Dressers), 86-16 XL and 94-02 Buell OEM frames (will also work on most aftermarket frames) Must be used with tool driver spacer and...

Jims 2233 - Tappet Tool - Oil Filter Plug

Tappet Oil Filter Screw Plug Tool Removes oil screen without removing exhaust Used to remove the tappet oil screen plug Made in the U.S.A.

Jims 2240-11-4 - Adapter - Valve Guide - Insert - 7 mm

Valve Guide Adapter Adapters are supported by a stand that makes it easy to press valve guides in and out Adapters for working on 7 mm valve guides Made in the U.S.A.

Jims 2246 - Timken® Bearing Race Installer

Timken® Bearing Race Installer Used to install bearing race straight into the left crankcase A must for late-model cases Made in the U.S.A.

Jims 2251 - Fork Tube and Leg Holder

Fork Leg Holder Tool Mounts in vise to hold fork firmly during repair without causing damage to fork assembly Holds fork legs and tubes for easy hands-free servicing or rebuilding Use on smaller 28 mm or larger fork tubes with a maximum 2” Will not...

Jims 2256 - Gear Seal Installation - Drive - 5-Speed

Driver Handle Use to install main drive gear oil seal to the proper depth with transmission assembled Includes protective sleeve for seal, which can be used to protect main drive gear inner bearings during installation Made in the U.S.A.

Jims 2260 - Sprocket Lock Tool - Big Twin

Pulley Locker Lock the transmission pulley for removing or installing pulley nut Made in the U.S.A.

Jims 2267 - Vise Stand - Cruise Drive

Cruise Drive Vise Stand Aligns transmission gears and shafts for installation Protects parts from damage during installation Allows for quicker, safer and easier assembly Made in the USA

Jims 2268 - Main Case Seal Installer Tool - 5-Speed

5-Speed Main Case Seal Installer Tool Ensures correct alignment, seal protection and depth when installing the seal Made in the USA

Jims 2312 - Primary Locking Bar Tool

Primary Locking Bar Immobilizes primary drive Allows for tightening with a torque wrench or loosening with a breaker bar Prevents damage to rotor or magnets sometimes caused by air-wrench Made in the U.S.A.

Jims 2315 - Primary Locking Bar - Big Twin

Primary Locking Bar Immobilizes primary drive Allows for tightening with a torque wrench or loosening with a breaker bar Prevents damage to rotor or magnets sometimes caused by air-wrench Made in the U.S.A.
